當前位置:網站首頁 / 行業專用開關電源 / LED顯示屏電源(200~500W)

產品中心

Product Center
型號查詢



1.超寬電壓調節,可適應2.8~5V電壓的需求;

2.超寬工作溫度(-40℃~70℃);

3.超薄, 超窄設計,節省空間;

4.輸出保護功能:輸出短路/過載/過壓;

5.全部使用105℃長壽命電解電容;

6.海拔>5000m工作設計;

7.100%滿載老化測試;

8.紋波小,良好的EMC特性.


機型說明:

VAT-顯示屏專用, H-高電壓176~264Vac輸入, U-寬電壓90~264Vac輸入, P-帶PFC功能 , 55L-寬度55mm,19H-高度19mm


產品 型號標題 功率 輸入
電壓
輸出
電壓
輸出
路數
效率
%
PFC 尺寸 安規認證 技術
手冊
樣品
申請
VAT-H200S-4.2-55L VAT-H200S-4.2-55L 200W 180~264Vac 3.0~5.1V 1 90 無 165*55*26.5mm VAT-H200S-4.2-55L VAT-H200S-4.2-55L VAT-H200S-4.2-55L
VAT-H200S-4.2-60L VAT-H200S-4.2-60L 200W 180~264Vac 4.1~5.1V 1 89 無 208*60*30mm VAT-H200S-4.2-60L VAT-H200S-4.2-60L VAT-H200S-4.2-60L
VAT-UP200S-4.5-55L VAT-UP200S-4.5-55L 200W 90~264Vac 2.8~5.1V 1 90 165*55*26.5mm VAT-UP200S-4.5-55L VAT-UP200S-4.5-55L VAT-UP200S-4.5-55L
VAT-UP200S-5-60L-AII VAT-UP200S-5-60L-AII 200W 90~264Vac 4.1~5.1V 1 89 208*60*30mm VAT-UP200S-5-60L-AII VAT-UP200S-5-60L-AII VAT-UP200S-5-60L-AII
VAT-UP200S-4.2-19H-B VAT-UP200S-4.2-19H-B 200W 90~264Vac 4.2V 1 91 146*55*19mm VAT-UP200S-4.2-19H-B VAT-UP200S-4.2-19H-B VAT-UP200S-4.2-19H-B
VAT-UP200-4.5-P-D VAT-UP200-4.5-P-D 200W 90~264Vac 4.5V 1 87 139.5*55*30mm VAT-UP200-4.5-P-D VAT-UP200-4.5-P-D
VAT-H300S-4.2-55L VAT-H300S-4.2-55L 300W 180~264Vac 3.3~5.1V 1 90 無 180*55*30mm VAT-H300S-4.2-55L VAT-H300S-4.2-55L VAT-H300S-4.2-55L
VAT-H300S-5-60L-A VAT-H300S-5-60L-A 300W 180~264Vac 4.1~5.1V 1 90 無 208*60*30mm VAT-H300S-5-60L-A VAT-H300S-5-60L-A VAT-H300S-5-60L-A
VAT-UP300S-4.6-55L-A VAT-UP300S-4.6-55L-A 300W 90~264Vac 4.5V ,4.6V ,5V 1 90 180*55*30mm VAT-UP300S-4.6-55L-A VAT-UP300S-4.6-55L-A VAT-UP300S-4.6-55L-A
VAT-UP300S-4.2-60L-A VAT-UP300S-4.2-60L-A 300W 90~264Vac 3.3~5.1V 1 90 208*60*30mm VAT-UP300S-4.2-60L-A VAT-UP300S-4.2-60L-A VAT-UP300S-4.2-60L-A
VAT-HP400S-5-46L VAT-HP400S-5-46L 400W 180~264Vac 5V 1 89 220*46*26mm
VAT-H400S-4.5-60L VAT-H400S-4.5-60L 400W 180~264Vac 3.3~5.1V 1 89 208*60*30mm
VAT-UP400S-4.5-60L-B VAT-UP400S-4.5-60L-B 400W 90~264Vac 4.1~5.1V 1 89 235*60*30mm VAT-UP400S-4.5-60L-B
VAT260UP4.6AC VAT260UP4.6AC 260W 90~264Vac 4.6V 1 91 165×55×23mm VAT260UP4.6AC
